Chemical Composition

CHEMICAL COMPOSITION OF STAINLESS STEEL CHEMICAL COMPOSITION % (BALANCE IRON)
AiSi	C%	Ni%	Cr%	Mn%	Si%	S%	P%	Cu%	Mo%	Ti%
	(Max)			(Max)	(Max)	(Max)	(Max)	(Max)	(Max)
201	0.15	0.3/1	16/18	7.5	1.0	0.030	0.06	2.0
202	0.15	.3/6	17/19	9.5	1.0	0.030	0.06	2.0
302	0.15	8/10	17/19	2.0	1.0	0.030	0.045
302CHQ	0.08	8.5/10.5		1.4/1.8			0.045	3/4
303	0.15	8/10	18/20	2.0	1.0	0.150	0.200		0.60
304	0.08	8/10	18/20	2.0	1.0	0.030	0.045
304L	0.030	8/10	18/20	2.0	1.0	0.030	0.045
316	0.08	10/14	16/18	2.0	1.0	0.030	0.045	0.75	2/3
316L	0.030	10/14	16/18	2.0	1.0	0.030	0.045	0.75	2/3
316Ti	0.030	10/14	16/18	2.0	1.0	0.030	0.045		2/3	5XL Min.
308	0.080	10/12	18/21	2.0	1.0	0.030	0.040
308L	0.030	12/15	22/24	2.0	1.0	0.030	0.040
309	0.20	12/15	22/24	2.0	1.0	0.030	0.045	0.75	0.75
309S	0.08	12/15	22/24	2.0	1.0	0.030	0.045	0.75	0.75
310	0.25	19/22	24/26	2.0	1.5	0.030	0.045
310S	0.08	19/22	24/26	2.0	1.5	0.030	0.045
317	0.08	11/15	18/20	2.0	1.0	0.030	0.045	0.75	3/4
321	0.08	9/12	17/19	2.0	1.0	0.030	0.045			5XC Min
										(0.75 Max)
409	0.08	0.50(Max)	10.5/11.75	1.0	1.0	0.030	0.045			6.Cmin
										(0.75 Max)
409M	0.03	0.60(Max)	11/12.5	0.8/1.2	0.75	0.030	0.045			5XC min
										(0.75 Max)
410	0.15	0.60(Max)	11.5/13.5	0.6	1.0	0.030	0.040		0.75
410S	0.08	0.60(Max)	12/14	1.00(Max)	1.0	0.030	0.040
416	0.15	0.60(Max)	12/14			0.030
420	over 0.15	0.60	12/14	1.0	1.0	0.030	0.040
430	0.12		16/18	1.0	1.0	0.030	0.040		6xC Min
430F	0.12		16/18	1.25	1.0	0.025	0.040		0.60
431	0.20	1.25/2.5	15/17	1.0	1.0	.15 min	0.060		0.75(Max)
440A	0.60/0.70		16/18	1.0	1.0	0.030	0.040
440B	0.75		16/18	1.0	1.0	0.030	0.040		0.75(Max)
440C	0.95	0.75 (Max)	16/18	1.0	1.0	0.030	0.040
446	0.20		21/23	1.5	1.0	0.030	0.040
